HEPA Class II A2 Biosafety Cabinets

HEPA Class II A2 Biosafety Cabinets

Product Details:

Place of Origin: CHINA
Brand Name: HAIYING
Certification: CE
Model Number: BHC-1300A2

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden case
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Get Best Price Contact Now

Detail Information

Type: Blood Testing Equipments Model: BHC-1300A2
Overall Size: 1500×750×1950mm Purification Area Size: 1300×650×580mm
Product Name: Biosafety Cabinet Inside Of The Door: 0.38±0.025m/s
Front Inflow Air: 0.48±0.025m/s Weight: 180kg
Highlight:

HEPA Class II A2 Biosafety Cabinets

,

HEPA biosafety cabinet class 2 a2

,

180kg Class II A2 Biosafety Cabinets

Product Description

Steel Structure Biological Safety Cabinet Class II A2 Biosafety Cabinets

Class II A2 Biosafety Cabinets Features:

◆ Three protection: operator, sample and environment.
◆ Airflow system: 70% air re-circulation, 30% air exhaust
◆ A2 Cabinet is suitable for working with microbiological research in the absence of volatile or toxic chemicals and radionuclide.

◆ Advantage:Using infrared remote control board to ensure that the working wind speed always maintains the ideal state
◆ Swivel casters with brake, fixed adjusting feet

◆ Have a front window operation safety cabinet, the operator can through the front window operation in safety enclosure.

◆ Airflow into the operation port to protect personnel

◆ Downdraft filtered by high efficiency filter to protect product

◆ The contaminated airflow is filtered by a high efficiency filter and discharged to protect the environment

◆ The visible front window is made of 6mm tempered glass, which is explosion-proof, UV-proof and non-reflective.

◆ The sliding front window adopts a suspension lifting system, which can be lifted and positioned arbitrarily, with reliable performance and maintenance-free. It is convenient for sterilization after being closed and sealed.

◆ The working area is made of standard 304 stainless steel, and the internal arc angle is designed without clean dead corners.



Model BHC-1300A2
Clean Grade HEPA:ISO 5 calss ( Class100 )
ULPA:ISO 4 Class ( Class10 )
HEPA Filter HEPA:≥99.995% , @0.3μm
ULPA:≥99.999% , @0.12μm
Air tightness 99.99≤E≤99.999
Overall Dimensions 1500×750×1950
mm
Working Space 1300×650×580
mm
Inside of the door 0.38±0.025m/s
Front inflow air 0.48±0.025m/s



Installation of Class II A2 Biosafety Cabinets:

1.  The biological safety cabinet shall not be placed on its side, impacted, or collided during transportation, and shall not be directly attacked by rain, snow, or sun exposure.

2.  The working environment of the biological safety cabinet is 10~30℃ and the relative humidity is <75%.

3.  The equipment should be installed on a horizontal surface that cannot be moved.

4.  The equipment must be installed close to a fixed power socket. When the external exhaust system is not connected, the top of the device must be at least 200mm away from the obstacle at the top of the room, and the distance between the back and the wall must be at least 300mm to facilitate the smooth flow of external exhaust. Maintenance of safety cabinets.

5.  In order to prevent airflow interference, it is required that the equipment should not be installed in the passages of people, and the operating port of the sliding front window of the biological safety cabinet should not be directly facing the doors and windows of the laboratory or too close to the doors and windows. Places that may disturb the airflow.

6.  When used in high altitude areas, the wind speed must be recalibrated after installation.
